10(40)
1.3.2 Specification List
Table 1-2: Specifications List (1)
Model
Item/
Parameters
SIC-3A SIC-5A SIC-8A SIC-10A SIC-12.5A
SIC-15A
Refrigerant
Capacity
1)
kW 7.35 12.5 19.5 26 30 38
Kcal/hr 6,321 10,750 16,770 22,360 25,800 32,680
Compressor
Power(50H
z/60Hz)
kW 2.55/ 3.96/ 6.11/ 8.06/ 9.11/ 11.8/
HP 3 5 8 10 12.5 15
Refrigerant
Weight (kg) 3.6 4.3 7 8 11 13
Control Mode Thermostatic expansion valve
Type R22
Evaporator Type Tube-in-shell style
Condenser
Type Tube-fin style
Blower (kW)
(50Hz/60Hz)
0.18 0.45 0.25×2 0.45×2 0.6×2 0.78×2
Water Tank Capacity (L) 30 85 150
Pump
2)
(50Hz)
Power (kW) 0.75/0.75/1.1 1.1 1.1/1.5/2.2
(L/Min) Pump
Flow (L/min)
50/83/67 80/100/89 130/150/133
Working Pressure
(kgf/cm
2
)
2.0/2.6/3.8 2.0/2.6/3.5 2.0/3/4.2
Total Power (kW) (50Hz/60Hz)(kW)
3)
3.48 5.16 7.71 10.06 11.41 14.81
Pipe
Coupling (inch)
Cooling Water
Outlet
1 1
1
/
2
2
Cooling Water
Inlet
1 1
1
/
2
2
Water Tank Outlet
1/2
Water Tank Port
1/2
Protective
Devices
Compressor Overload relay
pump Overload relay
Cooling Water
Circuit
High and low pressure switch/anti-freeze switch
Water Circuit Flow switch (optional) / water tank level sensor (optional) / bypass valve
Power(VAC)
4
）
3Φ,400V,AC 50HZ
Measures Exchange 1Kw=860 kcal/hr 1RT=3,024kcal/hr 10,000Btu/hr=2,520kcal/hr
We reserve the right to change
specifications without prior noice.
Note:
1) Refrigeration capacity is measured based on the flow 0.172 m
3
/ (h.k W) and the outlet temperature (7℃) of
chilled water under the environment temperature of 35℃.
2) Low pressure pump is for domestic and Southeast Asia export, customers can change for medium
pressure pumps (use P for short; e.g.: SIC-5A-P) or high pressure pumps (use HP for short; e.g.:
SIC-5A-HP), specific parameters in turn as shown above.
3) Pump power is included in total power.
4) Special orders of machine voltage can be acceptable according to customers’ requests.
