5
Characters,
Factory Default
Setting Item, Function, Setting Range
Stop bit
• Selects the stop bit.
• Selection item:
1 bit
2 bits
Response delay time
• Response from the controller can be delayed after receiving command from the host
computer.
• Setting range: 0 to 1000 ms
SVTC bias
• By connecting to Shinko programmable controllers [PC-900 or PCD-33A with the SVTC
(Set value digital transmission) option], digital SV via the SVTC command can be received
from programmable controllers.
Refer to Section ‘8. Set Value Digital Transmission’ on p.46.
SV adds SVTC bias value to the value received by the SVTC command.
• Setting range: 20% of input span
DC voltage, current inputs: 20% of scaling span (*)
Available only when Shinko protocol is selected in [Communication protocol].
(*) The placement of the decimal point follows the selection.
(Multiple times)
RUN mode
PV/SV Display
Now, settings are complete.
