Fix the Door block "A0091" on top and flush with the edge of the door frame. Attach the receiving clip
to the door and then clip the roller catch to the receiver and screw the receiver to the door block.
3mm
GB-IE
Door block
(A0091) x01
34mm`
34mm`
Roller catch
(A0090)X01
12mmScrew
(A0027) x04
60mmScrew
(A0056) x02
12
Step 08
(A0091)x01
Door
25mm 60mm
Door
12mm 12mm
