Attach the hinge on the outside long edge of the door using 6 screws into the door and 6 into the door panel
01
Assembly
These instructions are for your safety. Please read through them thoroughly before use .
Treat all the parts before assembly –see page 5
GB-IE
Door
(A0087)x01
75mm x 785mm
Continuous hinge
(A0088)x01
25mm Black Screw
(A0031)x04
Door panel
(A0086) x01
Black D handle
(A0089)x01
25mmScrew
(A0032)x12
Black D handle
(A0089)x01
3mm
Lay the Door panel "A0086" on the floor, lay the door evenly in position use another panel as
support.
Position the door handle about 20mm from the edge of the door
