Shire Pixie - Step 06: Casement Stay Fitting; Step 07: Wall Panel Assembly

GB-IE Drill both the "A1153 " panels as shown and screw to the ”A2954” panel with 2 x 60mm screws.
The cladding on the bottom of the panels overhangs the floor edge.
Floor
(A0085)x01
07
06
25mmScrew
(A0032)x12
Casement set
(A0038) x02
GB-IE Casement stay and pins must fit together loosely.
Fix the casement stay to the window insert first.
Then mark and fix the pins .
Back -Plain Panel
(A2954)X01
60mm screw
(A0035)x02
A1153
A2954
Side– Plain panel
(A1153)X01
3mm
5mm
