Shire Pixie - Step 18: L Bracket Attachment to Rail; Step 19: Post Alignment and Trimming

25
19
18
GB-IE Attach two " L Brackets A0686" to each rail .
GB-IE For each side, align, mark the post to the underside of the roof and trim.
25mm Screw
(A0032)x04
L Bracket
(A0686)x02
Assembly step 17
5mm
