21
20
GB-IE Position the "Rail assembly A3316", drill the roof and fix here and also the "L Bracket A0686" to the
wall.
GB-IE 3 Strips of felt have been supplied .
Fit the 2 lower ones first folding the felt over the roof edging, with an even overhang front and back
then secure with a couple of nails at the top to hold the felt in position and at the bottom nail at
approximately 100mm centres
The third piece overlaps the lower pair and goes over the ridge. Nail at approximately 100mm centres
25mmScrew
(A0032)x06
1.8m Felt strips
(A3318)x03
12mmFelt nails
(A0266) x106
Rail assembly
Steps 16-17
Tidying the corner
3mm
08
26
