Shire Pixie - Step 24: Roller Catch Attachment; Step 25: Securing Walls to Floor

24
GB-IE Attach the "Roller catch A0090" catch to the door and the body to the door frame .
Roller catch
(A0090)X01
Door Frame
Door
25
GB-IE Fix the walls to the floor with 2 x 60mm screws per panel
60mm Screw
(A0035) x8
12mmScrew
(A0027) x04
12
5mm
28
