8-2.Check parts unit
1. INDOOR FAN MOTOR
.MOTOR EXAMINE AND REPAIR
Circuit diagram：
AMS-07（09/12UR4SNVG（VT4、VL4、VQ4、UP4、UL4、UQ4、NS4、ZC4、ZA4）
1）YYW16-4-532：
BLACK
WHITE
M
A
Vcc
GND
Vout
BROWN
BLACK
YELLOW
WINDING
""
""
M The main winding
A The auxiliary winding
Capacitor
Hot protector 100
℃
AMS-18UR4SVVG3/VT3/VL3/UP3/UL3/UQ3
2）RPG25A-6
AMD-09/12UX4SJD
3）
YSK95-25-4HS10
M:329Ω A1：36.5Ω A2:31Ω A3:30.5Ω A4:34.2Ω A5:91Ω
