2-3. Other component specifications
2-3-1. INDUCTANCE
PARAMETER
Inductance model R2550HSA R2050HSB
Rated power source 220V 50Hz 220V 50Hz
Rated current(A) 25 20
Rated inductance
5.0(mH)±10% 5.2（mH）±10%
Ambient
temperature(℃)
-20℃～+70℃. -20℃～+70℃.
2-3-2. FILTER
ELECTRIC
PERFORMANCE
AMW3-24U4SKC
AMW4-28U4SKC
AMW3-24U4SZD
AMW3-20U4SZD
AMW4-36U4SAC
AMW2-20U4SNC
AMW2-16U4SGC
Filter model
RTNF-250T10X-3LF
RTNF250-30T10X-3LF RTNF250-25T068X-03LF
Rated current(A) 20 30 20
Rated power
source
AC 220V—50Hz AC 220V—50Hz AC 220V—50Hz
Filter frequency
range
150K—30MHz 150K—30MHz 150K—30MHz
Temperature
range(℃)
-25℃～+85℃. -25℃～+85℃. -25℃～+85℃.
2-3-4. STEPPER MOTOR
PARAMETER
Stepper Motor
model
24BYJ48
Voltage(DC) 12V
Number of phase 4
Drive mode 1-2phase excitation unipolar drive
Resistance per
phase
300Ω±7%
Temperature
range(℃)
-10℃～+40℃
