40
5-3. Sensor parameter
1. THE PARAMETER OF OUTDOOR COMPRESSOR DISCHARGE TEMPERATURE SENSOR:
（R
0
=187.25K±6.3%；R
100
=3.77K±2.5K；B0/100=3979K±1%）
T [ ℃ ] Rmin [ KΩ ] Rnom [ KΩ ] Rmax [ KΩ ]
DR(MIN)% DR(MAX)%
-30 908.2603 985.5274 1065.1210 -7.84 7.47
-29 855.3955 927.6043 1001.9150 -7.78 7.42
-28 805.9244 873.4324 924.8368 -7.73 5.56
-27 759.6097 822.7471 887.5944 -7.67 7.31
-26 716.2320 775.3041 835.9165 -7.62 7.25
-25 675.5881 730.8775 787.5529 -7.56 7.20
-24 637.4902 689.2583 742.2720 -7.51 7.14
-23 601.7645 650.2533 699.8601 -7.46 7.09
-22 568.2499 613.6835 660.1191 -7.40 7.03
-21 536.7970 579.3832 622.8658 -7.35 6.98
-20 507.2676 547.1989 587.9307 -7.30 6.93
-19 497.5332 516.9882 555.1565 -3.76 6.88
-18 453.4748 488.6192 524.3977 -7.19 6.82
-17 428.9819 461.9693 495.5191 -7.14 6.77
-16 405.9517 436.9251 486.3954 -7.09 10.17
-15 384.2888 413.3808 442.9105 -7.04 6.67
-14 363.9047 391.2386 418.9563 -6.99 6.62
-13 344.7169 370.4072 396.4325 -6.94 6.56
-12 326.6497 350.8019 375.2461 -6.88 6.51
-11 309.6286 332.3441 355.3104 -6.83 6.46
-10 293.5903 314.9620 336.5448 -6.79 6.41
-9 278.4719 298.5822 318.3744 -6.74 6.22
-8 264.2156 283.1464 302.2294 -6.69 6.31
-7 250.7678 268.5936 286.5448 -6.64 6.26
-6 238.0783 254.8686 271.7603 -6.59 6.22
-5 226.1003 241.9200 257.8193 -6.54 6.17
-4 214.7903 229.6997 244.6593 -6.49 6.11
-3 204.1073 218.1630 232.2612 -6.44 6.07
-2 194.0135 207.2681 220.5495 -6.39 6.02
-1 184.4732 196.9759 209.4913 -6.35 5.97
0 175.4533 187.2500 199.0468 -6.30 5.93
1 166.8952 178.0255 189.1529 -6.25 5.88
2 158.8023 169.3067 179.8058 -6.20 5.84
3 151.1467 161.0633 170.9724 -6.16 5.80
4 143.9026 153.2667 162.6216 -6.11 5.75
5 137.0455 145.8905 154.7246 -6.06 5.71
6 130.5528 138.9097 147.2544 -6.02 5.67
7 124.4033 132.3011 140.1856 -5.97 5.62
8 118.5769 126.0429 133.4946 -5.92 5.58
9 113.0550 120.1146 127.1591 -5.88 5.54
