Shivaki SSH-PM074DC - Page 66

9
9
.
.
P
P
A
A
R
R
T
T
S
S
L
L
I
I
S
S
T
T
69
1263768 G1C28/R00.02-02 1
UQ3
1313245 G2C03/R00.02-02 1
UP3
1380616 G2C02/R00.02-02(ZX) 1 UL3
-- -- -- VG3
1364810 G2C31/R00.02-02 VL3
18
-- --
ornamental plate（drawing）
-- VT3
1326018 G1C20/R00.05.01-03 1 UP3
1260739 G1C26/R00.02-03 1 UL3
1356581 G2C30/R00.02-03 1 VG3
19
1417671 G1K39/R00.02-02
display film（drawing）
1 VT3
1276586 G1C20/R00.05.01-02 1 UP3、UQ3、UL3
1338256 G1C60/00.05.01-01 1 VG3、 VL 3
20
1412963 G1K39/R00.05.01-01
display box
1 VT3
1241510 KGK-5941.01.03-00 1 UP3
1393142 K36430280 1 UQ3、UL3
1357097 K36430218 1 VG3、VL3
21
1417869 K36412713
display board
1 VT3
22 1338217 G1G00/R00.02-06
wiring distribution cover
assy
1
23 1362488 G2C00/R00.02-06 display panel 1
24 1223852 G2A00/R00.02.01-06 baffle 2
25 1345677 K331H0008 sensor mounting plate 1
26 1387643 K1C510077 Temperature Sensor 1
27 1225096 DG13B1-01 step motor 1
28 1248516 G2C00/R00.05-04
mounting plate
1
29 1260327 DG13G2-02 fan motor 1
30 1328841 +DG17D4-10 terminal panel 1
31 1223749 G1A00/R00.00-02
holder
1
32 1316391 +G2C00/R00.05-02 elec joint box cover 1
33 1222254 +DG20B0-08
transformer
1
34 1330937 +G2C10/R00.05-01 elec joint box 1
1387643 K1C510077 1
INDOOR SENSOR ASS'Y
35
1383891 DG19R5-10
Temperature Sensor
1
COIL SENSOR ASS'Y
1473170 +K36412216 1 VG3、VL3、VT3
36
1473839 +K364D0336
control board
1 UQ3、UP3、UL3
37 -- -- -- --
1465785
K36210304
1
H1
1465783
K36210303
1
J1
38
1342348
+DG11E4-07(HSN)
REMOTE CONTROLLER
1
E4-07
