Shivaki SSH-PM074DC - Page 68

9
9
.
.
P
P
A
A
R
R
T
T
S
S
L
L
I
I
S
S
T
T
90
KEY NO.
P
ART COD
E
PART NO. DESCRIPTION Q'TY NOTE
1 1403537 K31430114 FRONT PANEL
1
2 1405350 K38310026 propeller fan
1
fan
3 1339666 K37210136 compressor
1
A
TL232SDNC9AU
4 1474130 +RZA-2-2476-135-XX-0 noise-insulation cotton
1
5 1353069 K31120101 base parts
1
6 1382782 1382782 mounting plate
1
7 1400459 K31710028 upper cover
1
8 1446243 K1B310344 FAN MOTOR
1
9 1302261 RZA-4-2649-069-XX-0 Electromagnetic coil
1
10 1408125, K331F0057 motor bracket
1
11 1341294 K33670021 separate plate assy
1
12 1204958 RZA-2-5303-054-XX-0 sensor mounting plate
1
13 1357857 K37340271 condenser ASS'Y
1
14 1202234 RZA-2-2431-005-XX-0 rubber pad
1
15 1469447 K33370020 back guard filter
1
16 1258657 DG26D2-01(A) 4-WAY VALVE
1
17 1205798 RZA-4-2649-072-XX-0 Electromagnetic coil
1
18 1357312 K37450053 suction tube assy
1
19 1357614 K37440100 discharge tube assy
1
20 1307360 RZA-0-4207-075-XX-0 outlet tube ASS'Y
1
21 1203402 RZA-0-4505-008-XX-0 desiccation strainer
1
22 1357737 K37410397 pipe ASS'Y
1
23 1370562 K37580051 3/8 stop valve
4
24 1446363 K37570097 3/8 stop valve ASS'Y
4
25 1369915 K37580047 1/4 stop valve
4
26 1300307 RZA-0-4519-021-JT-0 electric expansion valve
4
27 1206640 RZA-4-2649-074-XX-0 Electromagnetic coil A
1
28 1206641 RZA-4-2649-075-XX-0 Electromagnetic coil B
1
29 1301887 RZA-4-2649-081-XX-0 Electromagnetic coil C
1
30 1312282 K37540002 Electromagnetic coil D
1
31 1203230 RZA-2-2475-017-XX-0 damping block
4
32 1384279 K37530035 electric expansion valve ASS'Y
4
33 8001840 RZA-2-2369-137-XX-0 valve cover
1
34 1301634 RZA-0-1115-001-XX-0 side panel parts
1
35 1474126 +K33AB0005 noise-insulation cotton
1
36 1366355 K16610032 fuse
1
37 1366386 K16B10004 fuse bracket
1
38 1473255
+K364A0002 filter board
1
39
1447469 K13410015 Power filter
1
40
1446293 K33540078
elec joint box assy
1
41 1202889 RZA-0-2239-023-XX-0 Fan ca
p
acito
r
1
