SHOWTEC Phantom 300 Beam - DMX Channels; Channels (BASIC)

14
DMX Protocol 14 Channels (BASIC)
Channel 1 - Horizontal movement (Pan)
Push the slider up, in order to move head horizontally (PAN).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 540° and stopped at any position you wish.
Channel 2 - Vertical movement (Tilt)
Push the slider, up in order to move head vertically (TILT).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 270° and stopped at any position you wish.
Channel 3 –PAN/TILT Speed
0-255
From Max Speed (0) to Min. Speed (255)
Channel 4 –PAN/TILT Macro
0-15
No Functions
16-45
Pan/Tilt Built-in Programs 1 (Fast)
46-75
Pan/Tilt Built-in Programs 2 (Fast)
76-105
Pan/Tilt Built-in Programs 3 (Fast)
106-135
Pan/Tilt Built-in Programs 4 (Fast)
136-165
Pan/Tilt Built-in Programs 5 (Slow)
166-195
Pan/Tilt Built-in Programs 6 (Slow)
196-225
Pan/Tilt Built-in Programs 7 (Slow)
226-255
Pan/Tilt Built-in Programs 8 (Slow)
Channel 5 – Shutter / Strobe (Dimmer must be open )
0-3
Shutter closed / Blackout
4-7
Shutter open
8-127
Strobe effect, from slow to fast (0-10 flashes/sec.)
128-159
Strobe effect Full open to Fade away, from slow to fast
160-191
Strobe effect Fade open to Full close, from slow to fast
192-223
Shutter open
224-251
Random strobe effect, from slow to fast
252-255
Shutter open
Channel 6 – Dimmer intensity
0-255
From black to brightest
