2
Technical Specifications
Product name SPARKULAR PRO
Model BT71/BT72
Dimension 315x290x285mm
Weight 16.5Kg
Input AC 220VAC-240VAC,50/60HZ; 600W Max.cascade: 5PCS;
AC 100VAC-120VAC,50/60HZ; 700W Max.cascade: 3PCS;
Work Temp. -20°C~50°C
Effect height HC8200 LARGE / HC8200 LARGEⅠ: 5~5.5m
Height adjstable Yes
Effect direction Straight up
Hopper capacity 1200g
Height adjustable Yes
HC8200 consumption rate 20g/min
Interface NEUTRIK POWERCON TRUE1, 3-pin waterproof DMX connectors
Control DMX
Operation Panel
LED display area:
READY: Flashing means heating up, about 5min. Turns from flashing into long on, indicates that the machine is ready
to work.
DMX: Flashing shows that DMX signal is connected, light OFF means there is no DMX signal
FAULT: Light ON when error occurs
HEAT: Light ON when system is heating up
READY DMX FAULT HEAT
Control Button Area:
MENU: switch through setup menu. Press 3s switch to advanced interface
DOWN: parameter down
UP: parameter up
ENTER: confirm and save parameters
