5
Step 4:
Take out the handlebar, then connect handlebar Wire A with computer Wire A.
Use Hexagon Socket Spanner, fasten handlebar to computer and handlebar support tube
by 9 and 10(Do not fix them tight!)
Notice: When assemble the handlebar to computer, ensure all sides of the armrest foam are
enclosed to the computer.
Half-round head
hexagon bolt,M8*15
Q’ty:2
Countersunk head
hexagon bolt,M8*16
Q’ty:1
9
10
9
10
A
A
2
