Pressure Boosting and Sprinkling 4
SPECIFICATIONS
Power Supply Required. ...................................115 Volts
Motor Duty ...................................................Continuous
Circuit Requirement (minimum) .....................15.0 Amps
Discharge Adapter .......................................................1"
BOOSTING CITY WATER PRESSURE
Hazardous pressure. Never run the pump
against a closed discharge. To do so can boil the water
inside the pump, causing hazardous pressure in the
pump causing the risk of explosion and possibly scald-
ing persons nearby. See Figure 1.
When using the pump as a high-pressure washer, use
only a reinforced high pressure hose or pipe for the dis-
charge line.
When using a garden hose, install adapters to the pump
suction and the discharge. The suction hose will require
two female ends. Either use a standard washing machine
supply hose or modify a short piece of standard 1" gar-
den hose as a suction line (See Figure 2).
Hazardous pressure. Do not shut off the
hose or the sprinklers while the pump is running.
The hose or sprinkler head may explode. For safety,
add a 75 PSI pressure relief valve.
Flow and Output Pressure Maximum
Model 0 PSI 10 PSI 20 PSI 30 PSI 40 PSI 50 PSI PSI
SDSS5 10 gpm 8.5 gpm 8.0 gpm 7.5 gpm 7.0 gpm 6.0 gpm 80
PERFORMANCE
