RF Sensitivity
−98 dBm at 10-5 BER
Latency Analog Output
2.08 msSTD
2.96 msHD
Audio Frequency Response
20 – 20 kHz (±1 dB)AD1
Note: Dependent on microphone typeAD2
Signal-to-Noise Ratio(Dynamic Range)
typical, 20 Hz to 20 kHz, receiver gain setting = -12 dB
UnweightedA-Weighted
117 dB120 dBXLR Line Output
126 dB130 dBDigital (AES3/Dante)
Total Harmonic Distortion
-6 dBFS, 1 kHz, System Gain @ +10
<0.01%
System Audio Polarity
Positive pressure on microphone diaphragm produces positive voltage on pin 2 (with respect to pin 3 of XLR output) and the tip of the 6.35 mm (1/4-inch) output.
Operating Temperature Range
-18°C (0°F) to 50°C (122°F)
1
Storage Temperature Range
-29°C (-20°F) to 65°C (149°F)
Audio Output
Gain Adjustment Range
−18 to +42 dB in 1 dB steps (plus Mute setting)
Configuration
Transformer Coupled Balanced (1=ground, 2=audio +, 3=audio
−)
XLR
Transformer Coupled Balanced (Tip = Audio +, Ring = Audio -,
Sleeve = Ground)
TRS
Impedance
100 Ω, Typical, XLR Line Out
Full Scale Output (200K Ωload)
+18 dBVLINE setting
−12 dBVMIC setting
+8 dBVTRS
1
Note: Battery characteristics may limit this range.
