Dynamic Range
1 kΩ load, @ 1 kHz
92 dB
Common Mode Rejection
10 to 100,000 kHz
45 dB, minimum
Preamplifier Output Clipping Level
at 1% THD
–7 dBV (0.5 V)
Mute Switch
−50 dB minimum
Logic Connections
LED IN Active low (≤1.0V), TTL compatible. Absolute maximum voltage: -0.7V to 50V.
LOGIC-
OUT
Active low (≤0.5V), sinks up to 20mA, TTL compatible. Absolute maximum voltage: -0.7V to 24V (up
to 50V through 3kΩ).
Cable
6.1 m (20 ft), attached, unterminated, three shielded audio pairs and three shielded conductors for logic control
Net Weight
594 g (1.3 lbs)
Environmental Conditions
Operating Temperature –18–57°C (0–135°F)
Storage Temperature –29–74°C (–20–165°F)
Relative Humidity 0–95%
Power Requirements
MX396/C-DUAL 48–52 V DC, 19.0 mA
MX396/C-TRI 48–52 V DC, 22.0 mA
