Shure Incorporated
4/14
Permanent Installation
Cable
The MX396 comes with a 20 ft. attached, unterminated cable.
Wire Color Function Mic Element
White Mic 1 Audio + A
Green Mic 1 Audio −
Orange Mic 2 Audio + B
Blue Mic 2 Audio −
