Specifications
Antenna Information:
✦ Type = Chip
✦ Gain = -4.32 dBi (left), -2.73 dBi (right)
Bluetooth 5:
✦ Operating frequency = 2402MHz-2480MHz
✦ Modulation scheme = FHSS
✦ RF power = +4 dBm (E.I.R.P.)
Supported Codecs:
✦ aptX™
✦ SBC
✦ AAC
Working Range:
10 m
Transducer Type
Single High-Definition MicroDriver
Sensitivity
at 1 kHz
107 dB SPL/mW
Impedance
at 1 kHz
17 Ω
Noise Attenuation
up to 37 dB
Frequency Range
21 Hz –17.5 kHz
Input Connector
MMCX connectors
Net Weight
20.8 g (.7 oz.)
Operating Temperature
0°C to 45°C (32°F to 113°F)
Storage Temperature
-29°C to 74°C (-20°F to 165°F)
