Transmitter reset: Place transmitters
in charging docks. Press and hold
reset button for five seconds to
restore transmitter factory settings.
Transmitter mute LEDs = flashing.
ɢ Power
LED
On = Charger is on
Off = Charger is off
ɣ Ethernet
Port
Connect to an Ethernet network to
enable remote device control and
monitoring using Wireless Workbench
or other control software.
ɤ Power
Input
Connect to power supply.
ɥ Charging
Status LEDs
Each charging slot has five LEDs that
illuminate to show the battery's charge
level:
LED % Battery Charge
1 Flashing:
<10%
Solid: >10%
2 >25%
3 >50%
4 >75%
5 100%
ɦ Charging
Slots (USB
3.0)
Slide any ULXD6 or ULXD8 transmitter
with Shure rechargeable batteries into
slots to begin charging.
ɧ Ethernet
Link Speed
Off = 10 Mbps
On = 100 Mbps
