SLX
mute se lect
SLX
mute sele ct
SLX1 & SLX2 Transmitters
Changing Batteries
• Expected life for an Alkaline battery is approximately 8 hours.
• When the transmitter light glows red, the batteries should be changed immediately, as
shown on the left.
On-off / mute switch
Press and hold to turn on or off. Press and release to mute or unmute.
To avoid accidentally muting the microphone during a performance, lock the front panel while the
microphone is in use.
Power / Infrared (IR) / Mute indicator
Green: ready
Amber: mute on
Flashing red: IR transmission in process
Glowing red: battery power low
Pulsing red: battery dead (transmitter cannot be turned on until batteries are changed)
Wearing the Bodypack Transmitter
Clip the transmitter to a belt or slide a guitar strap through the transmitter clip as shown.
For best results, slide the transmitter until the belt is pressed against the base of the clip.
8
SLX1
SLX2
