26
ULXD1
Mic Offset Range
0 to 21 dB (in 3 dB steps)
Battery Type
Shure SB900 Rechargeable Li-Ion or LR6 AA batteries 1.5 V
Battery Runtime
@ 10 mW
Shure SB900
>11 hours
alkaline
11 hours
See Battery Runtime Chart
Dimensions
86 mm x 66 mm x 23 mm (3.4 in. x 2.6 in. x 0.9 in.) H x W x D
Weight
142 g (5.0 oz.), without batteries
Housing
Cast aluminum
Audio Input
Connector
4-Pin male mini connector (TA4M), See drawing for details
Configuration
Unbalanced
Impedance
1MΩ,See drawingfordetails
Maximum Input Level
1 kHz at 1% THD
Pad Off
8.5 dBV (7.5 Vpp)
Pad On
20.5 dBV (30 Vpp)
Preamplifier Equivalent Input Noise (EIN)
SystemGainSetting≥+20
-120 dBV, A-weighted, typical
RF Output
Connector
SMA
Antenna Type
1/4 wave
Impedance
50Ω
Occupied Bandwidth
<200 kHz
Modulation Type
Shure proprietary digital
Power
1 mW, 10 mW, 20 mW
See Frequency Range and Ouput Power table, varies by region
ULXD2
Mic Offset Range
0 to 21 dB (in 3 dB steps)
Battery Type
Shure SB900 Rechargeable Li-Ion or LR6 AA batteries 1.5 V
Battery Runtime
@ 10 mW
Shure SB900
>11 hours
alkaline
11 hours
See Battery Runtime Chart
Dimensions
256 mm x 51 mm (10.1 in. x 2.0 in.) L x Dia.
Weight
340 g (12.0 oz.), without batteries
Housing
Machined aluminum
Audio Input
Configuration
Unbalanced
Maximum Input Level
1 kHz at 1% THD
145 dB SPL (SM58), typical
Note: Dependent on microphone type
RF Output
Antenna Type
Integrated Single Band Helical
Occupied Bandwidth
<200 kHz
Modulation Type
Shure proprietary digital
Power
1 mW, 10 mW, 20 mW
See Frequency Range and Ouput Power table, varies by region
Battery Runtime
Battery Type 1 mW 10 mW 20 mW
SB900 >11 hours >11 hours >7 hours
Alkaline <11 hours <11 hours <5.5 hours
NiMH <11 hours <11 hours <8 hours
Li-primary 12.5-18 hours 12.5-18 hours 9.5-12 hours
The values in this table are typical of fresh, high quality batteries. Battery
runtime varies depending on the manufacturer and age of the battery.
