3.3. Mechanicaldimensions
Figure3.3:FS/MF4701/03/08dimensions
Figure3.4:MF4712dimensions
Model N H1 H2 H3
FS4701/03 NPT1/8”,BSPT1/8” 39.0 20.0 10.0
MF4701/03
NPT1/8”,BSPT1/8” 43.0 24.0 12.0
FS4708 NPT3/8”,BSPT3/8” 43.0 24.0 12.0
MF4708 NPT3/8”,BSPT3/8” 47.0 24.0 12.0
