5.6 Analogoutput(0.5~4.5Vdc)

Theproductoffersavoltageanalogoutputoftheinstantflowrate.RefertoTable3.2forthewire
connectionforthisoutput.Themeteriscalibratedto110%ofthespecifiedfull‐scaleflowrate.The
typicalanalogoutputisindicatedbelow.Thisoverrangeappliestobothanalogand
digitaloutput.
Table5.7:MF4700analogoutput
Figure5.4:MF4700analogoutput

 
Flowrate
Analogoutput
(Vdc)
0.00 0.50
10%F.S. 0.90
20%F.S. 1.30
40%F.S. 2.10
50%F.S. 2.50
70%F.S. 3.30
90%F.S. 4.10
100%F.S. 4.50
110%F.S. 4.90
120%F.S. 4.90
