Page S.05 (CAN BUS) is dedicated to the COM status of the following networks: CAN0 (ECU INTERFACE -
Engine Control Unit.J1939 or MTU), CAN1 (PMCBUS - Power Management Communication Bus) and CAN2
(EX-BUS - Expansion-BUS).
communication status of bus.
There are three possible indications:
- ERROR-ACTIVE: normal operation
- ERROR-PASSIVE: communication is working despite faults (errors).
- BUS-OFF: Gen-set has interrupted the connection to the bus due to too many errors.
Communication error counters display. If the condition causing the malfunction has been eliminated, you can
force exit from the BUS-OFF condition on this page.
The error reset function, press the ENTER button, use the UP and DOWN buttons to select
the errors to reset. Hold down the ACK/TEST + EXIT buttons until the “RESET/DEFAULT ”
message is displayed. To exit error selection, use the EXIT button.
Pages S.06, S.07, S.08, S.09, S.10, S.11, S.12 and S.13 (SYSTEM STATUS) display the generic status of the
digital inputs.
Information!: Digital inputs assigned as Warnings, Lockouts or Power-offs do not come
under this category.
The generic status function, and the display priority of the same in the pages are pre-assigned when configuring
the system parameters.
Page S.14 (DIGITAL INPUTS) displays the status of the digital inputs of the Gen-set control module and the
expansion modules (available only if the DITEL expansion module/s is/are installed).
Pressing the ENTER button, scrolls through three different pages (LOGIC STATE, PHYSICAL STATE,
BY FUNCTION), showing the acquisition of digital inputs:
- LOGIC STATE: Active or inactive level according to a logic configuration that inverts the electrical signal
actually acquired.
- PHYSICAL STATE: Active or inactive level of the electrical signal actually acquired.
- BY FUNCTION: Displays the status of the main events related to the digital inputs.
Page S.15 (DIGITAL OUTPUTS) shows the status of the Gen-set control module's digital outputs. The status
of the expansion module outputs is only shown if the DITEL expansion module/s is/are installed.
Pressing the ENTER , button, scrolls through three different pages (LOGIC STATE, PHYSICAL STATE,
BY FUNCTION), showing the status of the digital inputs:
