22 DST4602Evolution User’s Manual
The Gen-set control module can display messages in various languages.
To select a different language, go to page S.03 (GEN-SET CONTROL MODULE STATUS). To change the
LANGUAGE press ENTER ; the square brackets [ ] will start flashing. Use the UP and
DOWN buttons to display the available LANGUAGES, then press ENTER to confirm or EXIT
to cancel the changes.
Gen-set implements the full management of the fuel pump, to pump fuel from the storage tank to the tank on
the generator. The pump can be managed automatically or manually using the controls on the front panel.
With the lockable selector in the MAN , AUTO or TEST position, select the E.XX“ENGINE MEASUREMENTS”
mode with the UP and DOWN buttons. Scroll through the pages using the LEFT or RIGHT
buttons until you reach page E.06 (FUEL PUMP). In this page you can start the standard setting
procedure by pressing the ENTER button (operating mode highlighted in contrast), and use the UP
and DOWN buttons to change the control mode. The following modes can be selected:
MANUAL-ON (pump on - the pump starts and will only stop when the max. fuel level is reached).
MANUAL-OFF (pump off)
AUTOMATIC (automatic pump - The pump starts and stops automatically, controlled by the minimum
and maximum level sensor).
Press ENTER again to confirm the mode.
With the lockable selector in position MAN , AUTO or TEST from any page or mode, you can open page "E.06
FUEL PUMP”" with the sequence of buttons SHIFT and EXIT .
Pressing the sequence of buttons SHIFT and EXIT again, you can change the fuel pump command
from:
MANUAL-ON (pump on - the pump starts and will only stop when the max. fuel level is reached).
MANUAL-OFF (pump off)
