Design and function
20 © SICK AG • Subject to change without notice • 8014868/YIF1/2020-10-19
4.2 Function
The DS35 and DT35 distance sensors are opto-electronic sensors for per-
forming non-contact distance measurement of objects.
The DL35 and DR35 distance sensors are opto-electronic sensors for per-
forming non-contact distance measurement on reective tape.
If Q1 and Q2 are used as switching outputs, the following operation modes
are available: Distance to Object (DtO), Window (Wnd), and Object between
Sensor and Background (ObSB). The measured distance value can be
transferred cyclically over IO-Link.
For the DT35 and DL35 models, the Q2 output can be congured as a cur-
rent output (4 … 20 mA), voltage output (0 … 10 V), or switching output.
