KTX-WB9114224UZZZZ | KTX Prime
色标传感器
接线图
Cd-384
+ (L+)
Q
A
U
- (M)
BN
WH
BU
1
2
3
Q
BK
4
操作方式
KTS/KTX Prime - 设置开关阈值（2 点示教）
When setting the contrasts to be
detected, “1st” flashes.
Press set button.
When setting the contrasts to be
detected, “2nd” flashes. Press set button.
The Quality of Teach is displayed.
Suitable for manual positioning of the object to be detected, e.g. marks and background.
1. Position mark 2. Position background
