Note:
These instructions do not purport to cover all
details or variations in equipment, or to
provide for every possible contingency to be
met in connection with installation, operation
or maintenance. Should further information be
desired or should particular problems arise
which are not covered sufficiently for the
purchaser’s purposes, the matter should be
referred to the local Siemens sales office.
The contents of this instruction manual shall
not become part of or modify any prior or
existing agreement, commitment or
relationship. The sales contract contains the
entire obligation of Siemens Industry, Inc. The
warranty contained in the contract between
the parties is the sole warranty of Siemens
Industry, Inc. Any statements contained herein
do not create new warranties or modify the
existing warranty.
Table of contents
Introduction 04 – 05
Receiving, handling and storage 06 – 08
Description 09 – 19
Control of Fusesaver 20 – 23
Installation 24 – 40
RCU commissioning 41 – 51
RCU operation 52 – 55
RCU maintenance 56 – 63
Technical data 64 – 67
Appendix 68 – 71
Abbreviations
FS Fusesaver
HV High voltage
IEC International Elecrotechnical Commission
LED Light-emiting diode
LV Low voltage
MLFB Order code
MV Medium voltage
PC Personal computer
RCU Remote control unit
SCADA Supervisory control and data acquisition
USB Universal serial bus
UTC Universal time coordinated
VT Voltage transformer
