8 3ZX1012-0RU21-1AA1
T1, T2, T3
NO/NC, A2
3RU2116-..J0 3RU2126-..J0 3RU2116-..J0, 3RU2126-..J0
PZ 2 ( 5 ... 6 mm)
M3: 0,8 ... 1,2 Nm
7 to 10.3 lb.in
M4: 2,0 ... 2,5 Nm
18 to 22 lb.in
M3: 0,8 ... 1,2 Nm
7 to 10.3 lb.in
d
2
= min. 3,2 mm
d
3
= max. 7,5 mm
d
2
= min. 4,3 mm
d
3
= max. 12,2 mm
d
2
= min. 3,2 mm
d
3
= max. 7,5 mm
— — —
d
2
d
3
!
NOTE
3RU2926-3BJ21
3RT2916-4EA13
3RU2916-3BJ21
3RT2916-4EA13
3RU2916-3BJ20
3RV2928-4AA00
3RU2126-..J03RU2116-..J0
L1 L2 L3
Q1
F2
F1 F3
M1
1/L1
3 ~
M
A1
A2
98
97
96
95
L1
STOP
Reset
Test
S
N
E2
E1
3RU1900-2A.71
3RU
3/L2
5/L3
2/T1
4/T2
6/T3
1/L1
3/L2
5/L3
2/T1
4/T2
6/T3
3RT
3RU21.6-...0
3RU21.6-...0 + 3RU29.
