9
Messerleiste nach vorn
schwenken.
Swing plug connector for-
wards
Messerleiste entriegeln und
nach oben abziehen.
Undo plug connector and
pull off upwards
Anlageseitige Schienen festschrauben
Bolt tight system-side bars
Anlageseitige Schienen festschrauben
Bolt tight system-side bars
Schrauben entfernen und Bedienpult abnehmen
Undo screws and remove control panel
