Digital electronic module 4DI DC24V ST (6ES7131-4BD01-0AA0)
Manual, 04/2007, A5E01077099-01
11
Diagnostics
2
2.1 Diagnostics using LED display
LED display



1
① Status display for input status (green)
Status displays
Event (LEDs)
1 5 2 6
Cause Remedy
On Input on channel 0 activated. —
On Input on channel 1 activated. —
On Input on channel 2 activated. —
On Input on channel 3 activated. —
