11 / 50
Siemens Actuators SAS.., SAT.. for valves CE1P4041en
Building Technologies Engineering 2015-05-19
2.7.2 Electrical accessories
· If auxiliary switches are used, their switching points should be indicated on the
plant schematic.
· Do not insulate the yoke and housing of the actuator and the valve stem, as air
circulation must be ensured.
· Non-observance of the above may result in accidents and fires!
· Do not touch the hot parts without prior protective measures to avoid
burns!
Stroke actuators SQS.. SAS..
ASC9.6 Auxiliary switch ASC9.6 ASC10.51
2.8 Spare parts
The following spare parts are available:
Stock number Description
8000069479 Housing cover with screws and
light conductor as an
assembly, without laser
marking
Notes
SAS..
SAT..
