Siemens Electromotoric actuators for valves A6V10628469_de--_c
Building Technologies 2018-03-12
Dimensions
Type
A B C C1 C2 D E ►►
SAY..P..
242 124 150 68 82 80 100 100 200
1.780
With ASK39.1
+25 154 300 200 100 - - - -
2.010
Dimensions in mm
Revision numbers
Product no. Valid from rev. no.
SAY31P03 ..A
SAY61P03 ..A
SAY81P03 ..A
