Electrical connections and connecting cable
Wire cross-sectional area
0.5...2.5 mm
2
, AWG 21...14
3)
Cable entries
4 x M20 (∅ 20.5 mm)
SKB..U
With knockouts for standard ½" conduit connectors
(∅ 21.5 mm)
SKB62/MO
Fixed connection cable
Cable length
0.9 m
Number of cores
5 x 0.75 mm
2
Degree and class of protection
Protection class
As per EN 60730
Automatic action
Type 1AA / Type 1AC / Modulation Action
Pollution degree
2
Housing protection upright to sideways
IP 54 as per EN 60529
Environmental conditions
Operation
IEC 60721-3-3
Climatic conditions
Class 3K5
Temperature, general
-15...<55 °C
Humidity (non-condensing)
5...95 % r.h.
Transportation
IEC 60721-3-2
Climatic conditions
Class 2K3
Temperature
-30...65 °C
Humidity (non-condensing)
5...95 % r.h.
Storage
IEC 60721-3-1
Climatic conditions
Class 1K3
Temperature
-15...55 °C
Humidity (non-condensing)
-5...95 % r.h.
Directives and standards
Product standard
EN 60730-x
Electromagnetic compatibility (Applications)
For use in residential, commerical, and industrial
environments
EU conformity (CE)
A5W00007751
4)
RCM conformity
A5W00007895
4)
EAC conformityt
Eurasia conformity for all SKB..
UL, cUL
AC 230 V
-
AC 24 V
UL 873 http://ul.com/database
Environmental compatibility
The product environmental declarations CE1E4564enX1 (SKB3.., SKB8..)
4)
, CE1E4564enX2 (SKB6..)
4)
and
A6V101083254 (external Modbus converter)
4)
contain data on RoHS compliance, materials composition,
packaging, environmental benefit and disposal.
