Siemens ACVATIX SKB Series User Manual

22
Siemens
CM1N4564en
Smart Infrastructure
2023-10-17
Dimensions / weight
Dimensions
See Dimensions [➙ 30]
Weight
SKB32.50, SKB32.50/F
9.15 kg
SKB32.51, SKB32.51/F
9.20 kg
SKB82.50
9.15 kg
SKB82.50U
9.45 kg
SKB82.51
9.20 kg
SKB82.51U
9.50 kg
SKB60
SKB62, SKB62/MO
9.20 kg
External Modbus converter
0.15 kg
SKB62U
SKB62UA
9.50 kg
Stroke inverter ASK51
1.0 kg
Materials
Housing
Die-cast aluminium
Bracket
Housing box
Plastic
Manual adjuster
Accessories
Auxiliary switch ASC1.6
SKB6..
Switching capacity
AC 24 V, 10 mA....4 A resistive, 2 A inductive
Double auxiliary switch ASC9.3
SKB32..,
SKB82..
Switching capacity per auxiliary
switch
AC 250 V, 6 A resistive, 2,5 A inductive
Potentiometer ASZ7.3
SKB32..,
SKB82..
Change in overall resistance of
potentiometer at nominal stroke
0...1000 Ω
Stem heater ASZ6.6
Operating voltage
AC 24 V ± 20 %
Power consumption
40 VA / 30 W
Inrush current
Max. 8.5 A
(Max. temperature 85 °C / 185 °F)
1)
At room temperature (23 °C); low ambient temperatures or high Δp may prolong these times
2)
From version ..L onward
3)
AWG = American wire gauge
4)
The documents can be downloaded at http://www.siemens.com/bt/download
