4
Siemens
CM1N4564en
Smart Infrastructure
2023-10-17
Electronics
SKB60
1)
1
Connection terminals
2
DIL switches
3
LED status indication
4
Stroke calibration
1)
From version ..L onward
DIL switches
Direction of operation
Fail-in-place (behaviour in
case of control signal loss)
**
Positioning signal Y
Positioning feedback U
Flow characteristic
ON
Reverse acting
Stops at current
position
DC 4...20 mA
lin = linear
OFF *
Direct acting
Closes
DC 0...10 V
log = equal
percentage
Relationship between
positioning signal Y and
volumetric flow
*
Factory setting: all switches OFF
**
Only considered when DIL switch 3 ON
(control signal = DC 4…20 mA)
SKB60
2)
, SKB62..
1
Connection terminals
2
DIL switches
3
LED status indication
4
Stroke calibration
2)
Up to and including version ..K
