Getting started10
VAR Language: English; VAR issue date: 31-Juli-2003
Insert SIM card/battery
The service provider supplies you
with a SIM card on which all the
important data for your subscription
is stored. If the SIM card has been
delivered in credit-card size, snap the
smaller segment out and remove
any rough edges.
• Remove the cover in the direction
of the arrow
1.
• Insert the SIM card in the opening
with the contact area facing
downwards and push gently until it
engages below the holder (make
sure the angled corner is in the
correct position
2).
• Insert the battery sideways into
the phone
3, then press down-
wards
4 until it engages.
• To remove, press the retaining tab
5 then lift the battery out.
• Slide cover over the phone
6
until it latches into place.
1
2
Additional notes
Always switch off phone before removing
the battery!
Only 3V SIM cards are supported. Please
contact your service provider if you have an
older card.
Functions without SIM card ...............p. 13
3
4
5
6
