2. Press key INFO on the above page and it will redirect to the home page as
follows:
Users can enter the login page by two ways: entering the password from template
or pressing and holding key ENTER on any page (except the error report pages).
On the login page, input 4-digits (0…9) password predefined in application for
different user levels.
1. Choose a digit by pressing key UP/DOWN.
2. Press key ENTER to confirm the input, and the input value will become an
asterisk “*” as follows.
Press key ESC to exit from the current page. Press and hold key ENTER
to re-enter the password.
3. Enter correct 4-digit password and it will go to the target page defined in
the HMI template. The corresponding user level will be shown on the
upper-right corner.
Entering password
from template
