1.2 Purpose and scope
This document provides information regarding the HMI-TM device, including its
functions and operations. The programming of HMI-TM is not covered in this
document, but shall be governed by the Climatix SCOPE.
The target readers of this document are technical personnel of OEM ACR
customer, who may use the information provided in this document to write user
manual for dedicated application.
1.3 Document conventions
The following symbols are used in this document to indicate warnings and notes:
This symbol draws your attention to special safety notes and warnings. Ignoring
such notes can lead to personal injury and/or major damage to property.
This symbol precedes the notes that must be observed in order to prevent
malfunctions or data loss.
Notes with this symbol provide important information requiring appropriate
attention.
Paragraphs with this symbol provide tips.
The following abbreviations are used in this document:
Board Support Package (operating system)
Human Machine Interface (operation unit)
Climatix Dot Matrix HMI POL895.xx
Climatix In-Built on POL4xx/6xx
Climatix Segmented HMI POL822.xx
Climatix Touch Panel HMI POL8Tx
Climatix Text Matrix HMI POL871.xx
Heating, Ventilating, Air Conditioning
Room Unit (e.g. POL822.xx)
Supervisory Control and Data Acquisition
Controller family with common tools
SCOPE commissioning and service tool
1.4 Human machine interface
The Climatix HMI-TM is designed for display, system configuration, set-up and
operation. It is a product of the Climatix range, supporting all Climatix range of
controllers.
The HMI-TM cannot be used to operate any 3
rd
-party devices.
