Siemens CP 1543-1 User Manual

Diagnostics and upkeep
5.2 Diagnostics with SNMP
CP 1543-1
54 Operating Instructions, 05/2017, C79000-G8976-C289-07
You will find detailed information on SNMP and the Siemens Automation MIB in the manual
"Diagnostics and Configuration with SNMP" that you will find on the Internet:
Link: (https://support.industry.siemens.com/cs/ww/en/ps/15392/man)
Performance range of the CP
The CP supports the following SNMP versions:
● SNMPv1
● SNMPv3 (with activated Security functions)
Traps are not supported by the CP.
Supported MIBs in SNMPv1
The CP supports the following MIBs:
●
MIB II (acc. to RFC1213)
The CP supports the following groups of MIB objects:
– System
– Interfaces
– IP
– ICMP
– TCP
– UDP
– SNMP
●
LLDP MIB
●
Siemens Automation MIB
Note the rights for writing to the MIB objects, see the next section (SNMPv3).
