Page #21 background image
Product overview, functions
2.6 Requirements for use
CP 1543-1
Operating Instructions, 05/2017, C79000-G8976-C289-07
21
2.6.3
Programming
Program blocks
For communications services, there are preprogrammed program blocks (instructions)
available as the interface in your STEP 7 user program.
Table 2- 1 Instructions for communications services
Protocol
Program block (instruction)
System data type
TCP Establish connection and
send/receive data via:
TSEND_C/TRCV_C or
TCON, TSEND/TRCV
(termination of the connec-
tion using TDISCON possi-
ble)
TCON_IP_v4
TCON_Configured
ISO-on-TCP
TCON_IP_RFC
ISO
TCON_ISOnative
UDP
TCON, TUSEND/TURCV
(termination of the connec-
tion using TDISCON possi-
ble)
TCON_IP_v4
E-mail
TMAIL_C TMail_v4
*
TMail_v6
*
TMAIL_FQDN
*
FTP
FTP_CMD FTP_CONNECT_IPV4
*
FTP_CONNECT_IPV6
*
FTP_CONNECT_NAME
*
FTP_FILENAME*
FTP_FILENAME_PART*
*User-defined data type
Table 2- 2 Instructions for configuration tasks
Function
Program block (instruction)
System data type
Configuration of the Ethernet
interface
T_CONFIG CONF_DATA
Refer to the documentation of the program blocks in the online help of STEP 7.
