Siemens CP 1543-1 User Manual

CP 1543-1
Operating Instructions, 05/2017, C79000-G8976-C289-07
57
Technical specifications
6
Note the information in the System description of SIMATIC S7-1500 (Page 9).
In addition to the information in the system description, the following technical specifications
apply to the module.
Technical specifications - CP 1543-1
Product name
Article number
CP 1543-1
6GK7 543-1AX00-0XE0
Attachment to Industrial Ethernet
• Number
1 x Ethernet (gigabit) interface
• Design
RJ-45 jack
• Transmission speed
10 / 100/ 1000 Mbps
Electrical data
Power supply
• via S7-1500 backplane bus
15 V
Current consumption
• From backplane bus
350 mA
• Power dissipation
5.3 W
Insulation
Insulation tested with
707 VDC (type test)
Design, dimensions and weight
Module format
Compact module S7-1500, single width
Degree of protection
IP20
Weight
Approx. 350 g
Dimensions (W x H x D)
35 x 142 x 129 mm
Installation options
Mounting in an S7-1500 rack
Permitted cable lengths
(Alternative combinations per length range) *
0 ... 55 m
• Max. 55 m IE TP Torsion Cable with IE FC RJ45 Plug 180
• Max. 45 m IE TP Torsion Cable with IE FC RJ45 + 10 m
TP Cord via IE FC RJ45 Outlet
0 ... 85 m
• Max. 85 m IE FC TP Ma-
rine/Trailing/Flexible/FRNC/Festoon/Food Cable with
IE FC RJ45 Plug 180
• Max. 75 m IE FC TP Ma-
rine/Trailing/Flexible/FRNC/Festoon/Food Cable + 10 m TP Cord
via IE FC RJ45 Outlet
