New functions Applications Customer benefits
Firmware update SINAMICS
Integrated via Web server
Firmware update of the SINAMICS Integrated
via the Web server of the CPU.
Remote maintenance:
Firmware updates possible via remote
access.
SINAMICS licenses for SINAM
ICS Integrated
The following SINAMICS functions are suppor
ted in addition for SINAMICS Integrated:
• Technology Extension DCDCCONV (DC-DC
converter)
• Technology Extension RAILCTRL (Rail Con
trol, under development)
Extended areas of application:
• Multi-carrier systems (MCS). Multi-carrier
systems are transport systems with linear
motors, which are used, for example, in
packaging machines and assembly
applications.
• With the SINAMICS Technology Extension
DCDCCONV, a Motor Module can be
employed as a chopper converter.
New SINAMICS Integrated
firmware
There is a new hotfix available for SINAMICS
Integrated, based on V5.2 SP3
Optimizations and extended module spec
trum (for example, SINAMICS S220 Smart
Line Modules in mixed mode operation with
SINAMICS S120 Motor Modules)
Achilles Level 2 Certification Achilles Level 2 Certification for Communica
tion Robustness
Greater safety of industrial plants
3.2 Application range
3.2.1 SIMATIC Drive Controller
Overview
The SIMATIC Drive Controller is a drive-based controller in the SIMATIC S7-1500 range.
A SIMATIC Drive Controller combines the following functionalities in a SINAMICS S120
Booksize Compact enclosure:
•
Fail-safe SIMATIC S7-1500 technology CPU with integrated technology I/Os
•
SINAMICS S120 drive control
The two components are referred to as "CPU" and "SINAMICS Integrated" in this
documentation.
The integrated SINAMICS S120 drive control is based on a CU320-2 Control Unit. It can
control
•
a maximum of 6 servo drives,
•
a maximum of 6 drives with vector control, or
•
a maximum of 12 drives with U/f control
Fail-safe technology CPUs are available in two performance classes. Safety Integrated on the
CPU side and drive side allows use in fail-safe applications.
The SIMATIC Drive Controller supports PROFINET and PROFIBUSDP communication.
16
SIMATIC Drive Controller
Equipment Manual, 11/2022, A5E46600370-AC
Product overview
3.2 Application range
