Evaluation of Data Matrix Code
You can evaluate the Data Matrix Code (DMC) using an appropriate reader or a smartphone
app. Suitable is, for example, the Industry Online Support Mobile App.
(https://support.industry.siemens.com/cs/ww/en/sc/2067)
NOTE
Note that the 2D codes and their content may vary depending on the delivery state.
Table 3-5Information on the nameplate
Nameplate DMC data string Feature Property (example)
1P6ES7615-4DF10-0AB0+ Article number (1P) 6ES7615-4DF10-0AB0
ST-L86065647 Serial number (S) T-L86065647
1Z FS: 01 Functional version (1Z) FS: 01
SIMATIC S7-1500, CPU 1504D
TF
Module name SIMATIC S7-1500, CPU 1504D
TF
X150 00-1F-F8-4A-0D-BC X150 00-1F-F8-4A-0D-BC
X160 00-1F-F8-4A-0D-C0 X160 00-1F-F8-4A-0D-C0
Front nameplate
X130 00-1F-F8-4A-0D-C2
MAC address interface X150,
X160, X130
X130 00-1F-F8-4A-0D-C2
Article number (1P) 6ES7615-4DF10-0AB0
MAC address interface X150
(23S)
001FF84A0DBC
Side nameplate 1P6ES7615-4DF10-0AB0+23S
001FF84A0DBC+ST-
L86065647
Serial number (S) T-L86065647
For detailed information on assigning the MAC address, refer to "MAC address assignment" in
the section PROFINET X150, X160 and X130 (Page 45).
40
SIMATIC Drive Controller
Equipment Manual, 11/2022, A5E46600370-AC
Product overview
3.7 Operator controls, displays and connection elements
