Building Technologies
CPS Fire Safety
Inputs / Outputs
FC121, FC122
– 2 monitored control lines 24 V / 500 mA for horns, fire controls, external remote
transmission.
– 1 dry output 30 V /1 A
– 2 programmable control inputs
FC123, FC124
– 2 monitored control lines 24 V / 500 mA for horns, fire controls, external remote
transmission.
– 1 dry output 30 V /1 A
– 3 programmable control inputs
Extensions
– Up to 6 monitored control lines 24 V / 1 A for horns, fire controls, external remote
transmission. (depending from the panel type)
– Up to 6 dry outputs 30 V / 1 A (depending from the panel type)
PMI
– Individual customer text for each zone
– User friendly operation via menu navigation
Commissioning
– Basic functions that can be adapted on-site if required without laptop
– Simple start up with preset default values
– Service function to view date and time of last alarm
Functional elements
Operating unit
The following are located on the operating unit:
– CPU module and the electronics for the operating unit
– Power supply
– Additional connection terminals for accessories
· 'Nordic SE' key switch
· LED display 12 x 2 LED
· EVAC Module
· Output card
Power supply 25 W and 70 W, emergency power supply
The power supply supplies the hardware and charges the batteries.
– The batteries supply the emergency power in case of power failure.
Configuration
For an easy configuration on site via integrated display no additional equipment is re-
quired.
Application ranges
The FC120 is ideally suited for small applications, e.g. in schools, small shops, hotels,
etc.
