Siemens FC123-ZA User Manual

Siemens Switzerland Ltd
Infrastructure & Cities Sector
Building Technologies Division
International Headquarters
CPS Fire Safety
Gubelstrasse 22
CH-6301 Zug
Tel. +41 41 724 24 24
www.siemens.com/buildingtechnologies
© 2014 Copyright by
Siemens Switzerland Ltd
Data and design subject to change without notice.
Supply subject to availability.
Document no. A6V10371354_e_en_-- Manual FS720
Edition 2015-01-16 Section 1
Details for ordering
Type Part no Designation Weight
Fire control panels
FC121-ZA S54400-C131-A1 Fire control panel (2Z) 1.840 kg
FC122-ZA S54400-C130-A1 Fire control panel (4Z) 1.845 kg
FC123-ZA S54400-C129-A1 Fire control panel (8Z) 4.113 kg
FC124-ZA S54400-C128-A1 Fire control panel (12Z) 4.128 kg
Expansion
FCA1203-Z1 S54400-B142-A1 Output card 2M 2R 0.064 kg
FTO1202-Z1 S54400-B119-A1 Zone ind. Field 12x2 LED 0.125 kg
FTO1203-H1 S54400-B118-A1 EVAC module (NL 8&12 Z) 0.112 kg
FTO1201-H1 S54400-B120-A1 EVAC module (NL 2&4 Z) 0.074 kg
FCA1209-Z1 S54400-B124-A1 Output module (230 V) 0.068 kg
FCA1206-Z1 S54400-S125-A1 Key switch set (Nordic SE) 0.065 kg
Power supply
FP120-Z1 S54400-S122-A1
Power supply kit A 70 W
3.920 kg
Batteries AX1213 4392990001
Battery 4 Ah
1.665 kg
FA2003-A1 A5Q00019353 Battery (12 V, 7 Ah, VDS) 2.450 kg
FA2004-A1 A5Q00019354 Battery (12 V, 12 Ah, VDS) 3.930 kg
FA2005-A1 A5Q00019677 Battery (12 V, 17 Ah, VDS) 5.640 kg
Spare part
FP2015-A1 S54400-B121-A1
Power supply (70 W)
0.575 kg

Siemens FC123-ZA Specifications

General

Brand	Siemens
Model	FC123-ZA
Category	Control Panel
Language	English
