Type Overview
Type Designation Order number Weight [kg]
FDA241 Aspirating smoke detector(8H) S54333-F17-A1 1.495
FDA221 Aspirating smoke detector(5S) S54333-F15-A1 1.495
Accessories
FDCC221S Communications interface S24218-A201-A2 0.019
FP120-Z1 Power supply kitA(70W) S54400-S122-A1 3.920
FA2003-A1 Battery (12V, 7Ah, VdS) A5Q00019353 2.450
FA2004-A1 Battery (12V, 12Ah, VdS) A5Q00019354 3.930
FA2005-A1 Battery (12V, 17Ah, VdS) A5Q00019677 5.640
FDAZ292 ASD filter box S54333-C92-A1 0.220
Spare parts
FDAZ292-AA ASD filter set S54333-S91-A1 0.009
FDAZ291 Aspirator (FDA241/FDA221) S54333-G1-A1 0.106
Product documentation
Document ID Title
A6V10334410 Technical manual Aspirating smoke detector FDA241, FDA221
A6V10393194 Technical manual Power supply kit A 70 W FP120-Z1
A6V10345654 Installation, Mounting Aspirating smoke detector FDA241, FDA221
A6V10340094 User Manual 'ASD Asyst Tool FXS2055'
A6V10728226 User Manual 'ASD Asyst Tool V2 FXS2056'
A6V10334435 Planning, Installation ASD Pipe system
A6V10332759 Installation, Operation Manual, Configuration 'ASD Configuration Tool FXS2051'
A6V10877841 Installation ASD Filterbox FDAZ292
A6V10916591 Installation Aspirator (FDA241/FDA221) FDAZ291
Related documents such as environmental declarations, CE declarations, etc., can be down-
loaded at the following Internet address:
http://siemens.com/bt/download
Notes
Disposal
The device is considered an electronic device for disposal in accordance
with the European Guidelines and may not be disposed of as domestic
garbage.
● Dispose of the device through channels provided for this purpose.
● Comply with all local and currently applicable laws and regulations.
